Right LOD for Your BIM Project

The right Level of Development (LOD) for your BIM project depends on the project phase, stakeholder needs, deliverables, and intended use of the BIM model. LOD defines how much detail and information a BIM element contains, ranging from conceptual massing to fully as-built models.

Common LOD Levels and When to Use Them:

• LOD 100 (Conceptual): Basic massing, approximate area, volume, and orientation. Used for feasibility studies and conceptual design, where details are indicative only.

• LOD 200 (Schematic): Generic elements with approximate size, shape, location, and orientation. Suitable for schematic designs, spatial planning, and early design analysis.

• LOD 300 (Design Development): Precise geometry, size, and orientation. This is appropriate for construction documentation and reliable clash detection. Shop drawings and coordination with other trades often begin here.

• LOD 350 (Construction Documentation): Adds details of how elements interface with other systems, such as supports and connections. This helps in construction coordination and pre-fabrication workflows.

• LOD 400 (Fabrication): Components are modeled with manufacturer-specific details, fabrication, and installation data. This level is required for prefabrication, installation, and detailed procurement.

• LOD 500 (As-Built): Represents the actual installed conditions for facility management and future renovations. Used post-construction for operations and maintenance.

How to Choose the Right LOD:

• Match LOD to Project Phase: Early phases (concept/design) use lower LOD, while later phases (construction/as-built) require higher LOD.

• Consider Stakeholder and Client Needs: Align LOD requirements with what is necessary for decision-making and downstream processes (e.g., contractors, facility managers).

• Avoid Over/Under Modeling: Over-modeling (too high LOD too soon) wastes resources, while under-modeling can lead to coordination failures and change orders.

• Document Your LOD Standards: Clearly define and communicate the target LODs in your BIM Execution Plan to manage scope, expectations, and accountability.

Summary:

Choose LOD suitable for the project's stage and the information needs of those using the model. For initial designs, LOD 100–200 suffices; for construction and prefabrication, LOD 300–400 is often needed; for handover and FM, LOD 500 is appropriate. Always clarify LOD expectations to prevent miscommunication and inefficiency.
