Contrast of CS Cone Crusher and HP Cone Crusher in Operation

Hydrocone crusher has become the main force in stone crusher team by virtue of its high productivity and stable performance. It has been a very popular type of crushing equipment in mining area. Hydrocone crusher mainly includes single cylinder hydraulic cone crusher(cs cone crusher) and multi-cylinder hydraulic cone crusher(hp cone crusher). And this passage mainly introduces the comparison between cs cone crusher and hp cone crusher in operation.

Contrast on the adjusting mode of their discharge ports

The adjustment of cs cone crusher discharge port is realized through single hydraulic cylinder lifting the moving cone. Cs cone crusher can easily realize automatic adjustment of the discharge port in the production process, at the same time, automatically display the discharge port size.

If users want to adjust the discharge port size of hp cone crusher, they must close down the equipment when there isn't material in its crushing chamber. Then, they can loosen the lock hydraulic cylinder and start the hydraulic motor on the adjusting ring. After finishing the discharge port adjustment of hp cone crusher, fasten the hydraulic cylinder again. The discharge port size of hp cone crusher must be manually detected.

Contrast of their overload and over-iron protection performance

CS cone crusher is very sensitive to provide overload and over-iron protection by setting single accumulator pressure.

HP cone crusher needs to set multiple accumulator pressure. Because this action cycle is long and the lock cylinder pressure is too high, so the overload and over-iron protection device of hp cone crusher is insensitive.

Contrast on whether CS cone crusher and hp cone crusher can realize the load start

Normally, cs cone crusher can start the operation with load, and it is simple and effective.But hp cone crusher must be started without load.

Reference: http://www.miningftm.com/news/contrast-of-cs-cone-crusher-and-hp-cone-crusher-in-operation/
