Video Surveillance 4CH WIFI IP Cameras NVR System

by Sarah Tan Sales Manager

CCTV Home Video Surveillance 4CH WIFI IP Cameras 1080P/960P/720P wifi NVR with 11" High Definition LCD display monitor

Key Features:

1080P/960P/720P Wireless Network Video Recorde
Built-in WIFI module with high-performance and high stability
Free Cloud Service, easy to achieve a variety of network
Automatically Connection between NVR and IPC
Support video preview/recording/playback/backup
Support the mixed use of wireless and wire, support different scene
Support Android/IOS/PC remote
Mobile surveillance supported,Including iPhone, iPad, Android
1HDD Max 4TB per HDD


Model NO. DR-W7604D
Operating system embedded Linux
System resources Simultaneously multi-channel real-time recording, playback, network operation, USB backup
Decode H.264(High Profile)
Monitor quality VGA, HDMI: HD
Video inputD1/960H/720P/960P/1080P
HDMI Output1CH, Resolution: 1024x768, 1280x1024, 1366x768, 1440x900, 1920x1080
VGA  Output1CH, Resolution: 1024x768, 1280x1024, 1366x768, 1440x900, 1920x1080
Playback quality 4CH
Encode ability 4*1080P
Multi-mode input Network:  4*1080P; 4*720P
Audio interface3.5mm headphone jack(Optional)
Record & Playback
Record modemanual>alarm>motion detection>timing
Local Playback4CH(local input mode)
Search mode Search by time, calendar, event, channel
Storage & backup
Storage1 SATA
Video storage  4TB for each HDD
External Interface
Audio interface3.5mm headphone jack(Optional)
Video output1CH VGA, 1CH HDMI
Network interface 1 RJ45 10M/100M self-adaption, 2 WIFI connector
PTZ control -
USB 2* USB 2.0 ports
HDD 1*SATA ports
Power Consumption<15W (without HDD)
Adapter Requirement DC12V 3A
Working Temperature -10  ~  +50
Storage Temperature 0  ~ +55
Working Humidity Less than 90% (no condensation)
Working Environment86kpa—106kpa
Dimensions 300*228*48mm
Net Weight 1.75kg
Gross Weight 2.50kg

Contact: Sarah
Skype: sarah88132280
Mobile/WhatsApp/Wechat: 86-13434788762
TEL: 86-755-26655864
FAX: 86-755-33566585
