Our Guide To GYLON Gaskets

by Accurate Rubber Accurate Rubber Corporation

Have you figured the unique buildings of Garlock's range of GYLON gaskets? This remarkable product scores highly for its superb chemical resistance, broad functional temperature array, as well as high tensile features. In this post, Accurate Rubber Firm speaks you via the structure and qualifications of GYLON gasket product

Accurate Rubber Firm is pleased to introduce that we are now providing GYLON gasket products from Garlock; the international leader in high-performance fluid securing and pipeline security products. While you may not of have actually heard of this special product, we're specific that by the time you've read this blog site, you'll likely want to hear much more.

What is GYLON?

GYLON is a PTFE product, available in a series of qualities for certain applications and/or sectors. It is produced utilizing a proprietary process that gives unique physical homes that are not obtainable through standard manufacturing techniques. GYLON gaskets are designed for serious chemical solution as well as are color-coded for simple identification.

Benefits of GYLON gasket product.

With superior chemical resistance for extreme environments, and a superb temperature level range, the Garlock branded GYLON product likewise attends to the problems of creep and also cool circulation that would usually be seen with virgin products and also those not made utilizing this unique Garlock procedure.

As part of the ingenious GYLON gasketing procedure, PTFE as well as fillers are reoriented to increase the material's tensile buildings and decrease creep leisure problems generally connected with PTFE products. Many thanks to this mixing process, you can anticipate an identical product that displays constant, premium physical properties that, unlike low-cost skived PTFE sheet materials, do not vary from one side of the sheet to an additional.

GYLON gaskets offer superior sealability, lowering process and also media loss, in addition to fugitive discharges, reduced creep and cool circulation attributes. A patented thermal bonding process is also employed to fabricate practically any type of dimension gasket.

GYLON gaskets from Accurate Rubber

Accurate Rubber can supply the following types of GYLON gaskets, which can run in temperatures ranging from -268 to +260 ° C, pressures varies between 800 as well as 1200 PSI, as well as come in densities ranging from 0.4 mm to 6.4 mm.

GYLON Design 3500 (Fawn GYLON includes PTFE with a silica filler, supplying improved efficiency over standard PTFE products, as well as lowering creep leisure as well as cool flow. This quality of GYLON is suitable for usage with solid acids (not hydrofluoric), solvents, hydrocarbons, water, heavy steam, chlorine and cryogenics. GYLON Design 3504 and Style 3505 (Blue GYLON are made up of aluminosilicate microspheres, suitable for usage with moderate focus of acids and some caustics, hydrocarbons, solvents, water, refrigerants, cryogenics as well as hydrogen peroxide. The Design 3505 is in addition NSF61 accepted for oxygen service.

Meanwhile, GYLON Style 3510 (Beige GYLON) is comprised of PTFE with a barium sulphate filler. It has actually been developed to provide excellent resistance to high concentrations of caustics, which are commonly located in the pulp and also paper sector. It is suitable for use with solid caustics, modest acids, chlorine, gases, water, heavy steam, hydrocarbons, cryogenics and aluminium fluoride.

GYLON Design 3540 Microcellular PTFE is extremely compressible, which suggests that it secures under low bolt load and also is as a result suitable for non-metallic flanges and also will conform to warped or damaged flanges. This type of GYLON gasket appropriates for use with strong caustics, solid acids, hydrocarbons, chlorine as well as cryogenics. The GYLON Style 3545 has similar high compression characteristics, and appropriates for use with similar media as the 3540. Nonetheless, these FDA accepted gaskets differ in that they have outer layers with an inflexible PTFE core, which decreases cool flow as well as creep.

Ultimately, GYLON Design 3565 ENVELON is PTFE gasketing with aluminosilicate microsphere filler. A soft, deformable outside adapts appear abnormalities, while the steady blue core enhances cool flow resistance. A reduced bolt-load need suggests that a tight seal can be achieved on glass-lined or imperfect flanges, and the direct sintering of GYLON layers prevents leakages as well as glue contamination. This kind of GYLON gasket appropriates for use with modest focus of acids and also caustics, hydrocarbons, solvents, cryogenics and also glass-lined devices.
