The BATCAM FX, developed by SM Instruments, is an advanced partial discharge camera designed to deliver high-precision inspection and analysis of electrical equipment. As partial discharge (PD) is one of the earliest indicators of insulation deterioration or defects in high-voltage systems, accurate partial discharge measurement is essential for preventing equipment failure and ensuring electrical reliability. The BATCAM FX helps industries visualize and locate partial discharge activity in real time, enabling engineers to take immediate action before minor issues escalate into significant damage.

Partial discharge occurs when insulation within electrical equipment becomes stressed, contaminated, or aged, resulting in localized electrical breakdowns. If left undetected, PD can lead to power outages, equipment damage, or safety hazards. The BATCAM FX addresses these challenges with advanced UV imaging technology that detects corona and surface partial discharge even in bright outdoor conditions. This makes it an ideal non-contact inspection tool for substations, transformers, switchgear, insulators, and high-voltage transmission lines.

SM Instruments designed the BATCAM FX to provide unmatched ease of use and mobility. Its lightweight and ergonomic body makes it suitable for both field inspections and indoor maintenance work. Equipped with high-sensitivity UV sensors and fast image processing capabilities, the camera delivers clear, real-time visualization of partial discharge activity. Engineers and technicians can instantly pinpoint PD locations, assess discharge severity, and capture detailed images or videos for documentation and reporting.

The BATCAM FX offers significant advantages for predictive maintenance programs. By enabling regular partial discharge measurement, organizations can detect early signs of insulation degradation and plan maintenance proactively. This reduces the risk of unexpected breakdowns, minimizes operational downtime, and enhances overall system safety. The device’s ability to store inspection data also supports long-term monitoring and trend analysis, helping maintenance teams make informed decisions based on accurate, consistent measurements.



If you are looking for a partial discharge camera, you can find them at SM Instruments.
