How Do Temperatures Affect the Performance of a Pressure Gauge?

by JUN YING INSTRUMENTS JUN YING INSTRUMENTS



Pressure gauges are frequently employed in difficult conditions where they'd be damaged or compromised by exposure to high or low temperatures. Excessively high temperatures can originate from a variety of sources, including the ambient environment or the processing medium itself (media temperature).



What can you do to preserve your sanitary pressure gauge transducers from corrosion & decrease the impacts of temperature on the instrumentation? The temperature will significantly impact the performance of pressure gauges, so this article will explain how you can mitigate those effects. A pressure valve or a sensor is referred to as an instrument.



Pressure Gauges and the Effects of Temperature -



There is a defined temperature range in which pressure gauges can be used. Because of their design and building, gauges may be damaged if used outside their operating temperature range.



Temperatures more than 150°F may cause dial discolouration & gasket hardness. Standard glass panes on non-liquid-filled gauges allow for continuous operation at temperatures of up to 250°F (121°C).



However, in liquid-filled pressure gauges, glycerin fill & RTD PT-100 start to yellow at 200°F (93°C). While gauges with weldment can sustain temperatures of up to 750°F (400°C) for short periods of time, those with silver weld joints can only withstand temperatures of 450°F (232°C) before rupturing and losing their calibration.



A diaphragm seal, capillaries, or suction is advised when operating at temperatures above 250 degrees Fahrenheit (121 degrees Celsius). Cold temperatures can affect the response time of a typical dry gauge.


The temperature in the Environment -



The sensor or Industrial thermowell's air temperature is the temperature of the air around it. An example of elevated air temperatures is a Liquid Filled Gauge or sensor located near a heat source, such as an oven.



Even in Siberia's harsh winters, the equipment can measure temperatures down to -78°F (-61°C). The instrument must be protected at both ends of the spectrum.


 The temperature of the process



Specifically, this is a measurement of the media's surface temperature when it comes into contact with the device's wetted surfaces. The process connection pressure sensor, with, in most instances, the Bourdon tube as well as tip, are all included in a pressure gauge.



In the case of a transducer, the procedure connection and the pressure sensor are normally included. It is good to take precautions if the instrument's maximum operating temperature is exceeded.


The temperature in the Storage



Always follow the manufacturer's recommended storage temperature. Prevent condensation & humidity by storing Ashcroft instruments indoors or in a clean, clean, well-ventilated environment. Depending on the setup, storage temperature restrictions might range from -40°F - 250°F (121°C to 121°C).



Electronic Indicators of Pressure



As an electro-pneumatic instrument measures its core temperature & compensates its output signal, the temperature control procedure is completed.



Although temperature variations are substantial, it is far more likely that such a constant and even Manometer temperature profile is produced and the temperature correction is working properly in long-term (hours or days) applications.



There are a number of ways to lessen the excessive temperature impacts in applications where the media temperature fluctuates rapidly, but the rest of the environment remains the same.
