Dual Cameras for Vehicle Security System
1/3 DSP Dual Cameras for vehicle video management system
Features:
Aluminum allow housing
Wide angle lens
Cam2 120dB Real WDR
Strong light inhibition
Cam1 Build-in IR LED
Cam1 Audio optional
Cam1 Option 720P AHD/1000 TVL CVBS output
Specification
Camera 1
Model |
DR-MDC01B-701-25 |
|
|
Image Sensor |
1/ |
|
|
Picture Elements |
PAL |
976 (H) x 582 (V) |
|
NTSC |
976 (H) x 494 (V) |
|
|
Horizontal Resolution |
700TVL |
|
|
Sensitivity |
0 Lux (Infrared LED On) |
|
|
S/N Ratio |
More than 48 dB, (AGC Off) |
|
|
Auto Gain Control (AGC) |
Auto |
|
|
White Balance |
Auto |
|
|
Back Light Compensation |
Auto |
|
|
Infrared Spectrum |
850nm |
|
|
Infrared LED |
6 LEDs |
|
|
Video Output |
1 Vp-p, 75Ωcomposite |
|
|
Audio Output |
Optional |
|
|
Mirror |
Optional |
|
|
ICR |
N/A |
|
|
Lens |
f2.5mm Standard Lens |
|
|
Pan Adjusting |
0-50° |
|
|
Tilt Adjusting |
0-50° |
|
|
Power Supply |
9-18V DC |
|
|
Power Consumption |
120mA |
|
|
Weatherproof/Water Proof |
N/A |
|
|
Operating Temperature |
-25°C to +55°C |
|
Camera 2
Model |
DR-MDC01A-603S-25 |
|
Image Sensor |
1/ |
|
TV System |
PAL/NTSC (Optional) |
|
Picture Elements |
756 (H) x 512 (V) |
|
Horizontal Resolution |
Better than 600TVL |
|
Sensitivity |
0.1 Lux/F1.2 |
|
S/N Ratio |
47.9dB |
|
Auto Gain Control (AGC) |
Auto |
|
Electronic Shutter |
Auto |
|
|
